    Solar Bracket / PV Bracket For Single Axis Independent Solar Tracker

    Ask Lasest Price
    Brand Name : Good Future Solar
    Model Number : MG/ZG/YG/JG.ETC SOLAR SYSTEM
    Certification : CE/ISO/BV/SGS.etc
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000MW per Month
    Delivery Time : 30 Working Days after design confirm
    • Product Details
    • Company Profile

    Solar Bracket / PV Bracket For Single Axis Independent Solar Tracker

    Hot Selling Reliable Quality Solar Bracket/PV Bracket for Single Axis Independent Solar Tracker

    Working principle:

    1. The structure is simple, the parts are highly pre assembled, and the construction time is saved.
    2. Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.
    3. Strong wind protection, optional with rain cleaning mode, automatic snow removal mode.
    4. IP66 aviation plug connection is adopted, and the system is free of debugging.
    5. It can communicate with the inverter in real time, read the output data of the inverter and calculate the best tracking angle.
    6. Photovoltaic power generation can be increased by 24-43%.


    Functions:

    1. Max gradient difference adaptability in N-S direction up to 15%.
    2. Excellent compatibility with all the mainstream solar modules available in the market, framed, frameless and bi-facial.
    3. Independent 2V module design, which reduces the quantity of piles and the construction cost significantly.
    4. Free obstacles among trackers in N-S direction, easy to maintain and clean.
    5. Multi-point drive, within 20 meters length for each tracker in the north-south direction, which greatly reduce the impact of wind torsion to the structure, improve the critical anti-wind capability, and avoid the instability that the traditional 2V system may have in extreme weather.
    6. Design configured with one single set of controller, which ensures point-to-point real-time monitoring, easy to detect fault points in time and reduce output loss.


    Technical Parameters

    Hot Selling Reliable Quality Solar Bracket/PV Bracket for Single Axis Independent Solar Tracker
    Tracking Range士 60°
    Driving SystemSlew drive, 28VDC motor
    Modules per TrackerMax.90 modules per tracker
    System Voltage1000 V or 1500 V
    Ground Coverage Ratio≥ 25%
    Power Consumption0.2-0.5kWh/day
    Power Supply ModePowered by PV strings, back-up lithium battery
    Standard Design Wind Speed18m/s
    Module SupportedAll commercially available modules
    Operation Temperature-40℃ - +60℃
    Control AlgorithmAstronomical algorithms + Tilt sensor close loop
    Tracking Accuracy≤ 1°
    String-PoweredYes
    BacktrackingYes
    Communication OptionsLoRa wireless /RS 485 cable
    Night PositionYes

    Welcome to Join Good Future Solar


    Good Future Solar is a professional solar power plant tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.Solar Bracket / PV Bracket For Single Axis Independent Solar Tracker
