    1500V Solar Bracket / PV Bracket For 1 Axis Solar Tracking System

    Ask Lasest Price
    Brand Name : Good Future Solar
    Model Number : MG/ZG/YG/JG.ETC SOLAR SYSTEM
    Certification : CE/ISO/BV/SGS.etc
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000MW per Month
    Delivery Time : 30 Working Days after design confirm
    • Product Details
    • Company Profile

    1500V Solar Bracket / PV Bracket For 1 Axis Solar Tracking System

    Hot Selling Competitive Price Solar Bracket/PV Bracket for Single Axis Independent Solar Tracker

    Working principle:

    Ground mounting single axis solar tracking system components slew drive solar panel mounting brackets is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).


    Functions:

    1) It can respond to site features and changing weather conditions, and conditions to continuously optimizing the tracking algorithm of each individual row, to make boost solar power system production.
    2) The most promising product technology trends in solar today. which help users get more power generated.
    3) Simple structure ,easy in installation and debugger application.


    Technical Parameters of Single Axis Solar Tracker

    Hot Selling Competitive Price Solar Bracket/PV Bracket for Single Axis Independent Solar Tracker
    Tracking Range士 60°
    Driving SystemSlew drive, 28VDC motor
    Modules per TrackerMax.90 modules per tracker
    System Voltage1000 V or 1500 V
    Ground Coverage Ratio≥ 25%
    Power Consumption0.2-0.5kWh/day
    Power Supply ModePowered by PV strings, back-up lithium battery
    Standard Design Wind Speed18m/s
    Module SupportedAll commercially available modules
    Operation Temperature-40℃ - +60℃
    Control AlgorithmAstronomical algorithms + Tilt sensor close loop
    Tracking Accuracy≤ 1°
    String-PoweredYes
    BacktrackingYes
    Communication OptionsLoRa wireless /RS 485 cable
    Night PositionYes

    Good future solar has a professional management team, we have gains rich experiences on the solar power generation, and the designing, manufacturing, commissioning of the single axis tracking system. Our company always values customer’s needs as the highest priority, ready to provides technical support to our customers at any time, to solve their problems in the operation of PV power plant and solar tracking system. With the mission of developing clean energy and protecting the environment, we believe that through close cooperation with domestic and foreign customers, we will continue to innovate in technology and management, and create a bright future of clean energy!
