    Customized Power One Axis Solar Panel Tracker Drive Simple Structure

    Ask Lasest Price
    Brand Name : Good Future Solar
    Model Number : MG/ZG SOLAR SYSTEM
    Certification : CE/ISO/BV/SGS
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000MW per Month
    Delivery Time : 30 Working Days after design confirm
    • Product Details
    • Company Profile

    Customized Power One Axis Solar Panel Tracker Drive Simple Structure

    Customized Power One Axis Solar Panel Tracker Drive With Factory Price

    Working principle:

    Horizontal single axis tracking system implements distributed actuation architecture, enabling each row to be independently controlled by its own motor with the tracking method “Astronomical algorithm + closed-loop control”. making the system accurate and reliable,real-time closed-loop feedback tracking angle, automatic tracking, without human intervention.

    The system is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).


    Functions:1) Power generation efficiency increased by 35%~40%.
    2) Simple structure ,easy in installation and debugger application.
    3) Adopting advanced good quality components in inclination,electric parts and actuator parts.
    4) The tracker could adjusts solar panels into horizontal when meeting strong wind.
    5) Adapt to outdoor environment,working temperature -40~80C°.
    6) Running in a high automation and intelligence,no pollution.
    7) Hot-dipped zinc galvanization will extend the work life of the brackets


    Technical Parameters of single axis solar tracker

    Customized Power One Axis Solar Panel Tracker Drive With Factory Price
    Tracking Range士 60°
    Driving SystemSlew drive, 28VDC motor
    Modules per TrackerMax.90 modules per tracker
    System Voltage1000 V or 1500 V
    Ground Coverage Ratio≥ 25%
    Power Consumption0.2-0.5kWh/day
    Power Supply ModePowered by PV strings, back-up lithium battery
    Standard Design Wind Speed18m/s
    Module SupportedAll commercially available modules
    Operation Temperature-40℃ - 70℃
    Control AlgorithmAstronomical algorithms + Tilt sensor close loop
    Tracking Accuracy≤ 1°
    String-PoweredYes
    BacktrackingYes
    Communication OptionsLoRa wireless /RS 485 cable
    Night PositionYes

    Customized Power One Axis Solar Panel Tracker Drive Simple StructureCustomized Power One Axis Solar Panel Tracker Drive Simple StructureCustomized Power One Axis Solar Panel Tracker Drive Simple StructureCustomized Power One Axis Solar Panel Tracker Drive Simple Structure
