    single axis technology axial manufacturer solar power plant tracker

    Ask Lasest Price
    Brand Name : Good Future Solar
    Model Number : photovoltaic Tracking System
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000MW per Month
    Delivery Time : 30 Working Days after design confirm
    • Product Details
    • Company Profile

    single axis technology axial manufacturer solar power plant tracker

    single axis technology axial manufacturer solar power plant tracker

    How do solar trackers work?


    The direction of the solar power plant tracker can be controlled by a pre programmed path based on astronomical prediction, or the solar radiation sensor can be used to respond to the current position of the sun. The Good future solar Plant tracking system adopts "astronomical algorithm + closed-loop control" to ensure accurate tracking angle. We don't use the sensor because it will lose its sense of direction at dawn and cloudy, so a backup tracking system is needed in the latter case.


    Product Introduction


    Horizontal single axis tracking system means that PV modules are mounted on a horizontal axis and track the sun in the east-west direction along the horizontal axis. Horizontal single-axis tracking system is mainly composed of: solar cell module mounting bracket, horizontal rotating shaft, rotating driving mechanism, wind speed detection device and tracking controller.The system is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).


    Parameters of solar power plant tracker


    Technical Parameters
    Tracking Range士 60°
    Driving SystemSlew drive, 24VDC motor
    Modules per TrackerMax.90 modules per tracker
    System Voltage1000 V or 1500 V
    Structure MaterialHot dipped galvanized/Pre-galvanized steel
    Power SupplyPowered by photovoltaic strings,back-up lithium battery
    Module SupportedAll commercially available modules
    Operation Temperature-30℃ - 60℃
    Control AlgorithmAstronomical algorithms + Tilt sensor close loop
    BacktrackingYes
    Night PositionYes

    single axis technology axial manufacturer solar power plant tracker


    Choose Good Future solar power plant tracker will Provide Some Advantages:

    1. Weight-lifting structure with 5 supporting points, shaped table design combined with a four-link age structure,driven by slewing drive.
    2. Adapt to outdoor environment,working temperature -40~80C°.
    3. The structure is simple, the parts are highly pre assembled, and the construction time is saved.
    4. Hot-dipped zinc galvanization will extend the work life of the brackets
    5. Automatic control: The solar tracking system will provide protection automatically for different weather (rain, snow, high winds, etc. )
    6. Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.

    Customized Functions


    Lora/CAN

    Steel frame basis

    Self-powered

    Surroundings adapt custom made

    Rain and snow mode

    According to Customer request custom made


    Company Introduction


    Good Future Solar is a professional solar power plant tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.
