High Performance Easy Installation Horizontal Smart Solar Tracking
System
Design Type of Solar Tracker
Normally the solar trackers could be classified to be single or
dual axis model according to the design and angle movement type.
Good future 1P/2P Smart Solar Tracking System is the single axis
trackers, it has one degree of freedom that acts as an axis of
rotation. Solar trackers can either have a horizontal or a vertical
axis. Good future Smart Solar Tracking System is horizontal type
and is used in regions where the daytime is short and sun gets very
high at noon. The vertical type is used in high latitudes where
summer days are very long but sun does not get very high.
Who we are?
Good Future Solar is a professional solar tracker supplier
specializing in the design, development and production of solar
tracking brackets. The company is a professional solar tracker
global solution experts, we focus on low cost and low maintenance
solution to create maximum value for customers. We are adhering to
the concept of continuous in innovation in design and operation,
committed to providing innovative technology and providing
efficient and good quality solutions and safe products for global
solar photovoltaic power plants.
What is a solar tracker?
Targray wholesale solar tracking solutions are supported by
procurement, supply chain financing and inventory management
programs designed to help mid-sized and large solar PV businesses
unlock value and enhance their bottom lines through process
improvements and working capital optimization. For more information
on how we can support your solar tracking system procurement
requirements, contact the Solar Division.
Parameters of Smart Solar Tracking System
| Technical Parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by PV strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
How do solar trackers work?
With a fixed structure solar system, sunlight irradiate on the
panel at a varying angle throughout the day, in the morning and
evening, its power generation is lower because the narrower the
angle of incidence, the higher the output. So with a solar tracker,
panels can follow the sun as it moves across the sky, keeping the
rays perpendicular to produce the most electricity.
The orientation of the tracking system can either be controlled by
a pre-programmed path based on astronomic predictions, or use solar
radiation sensors to react to the current position of the sun. Good
Future Solar tracking system use “Astronomical algorithm +
closed-loop control” to make sure a precise tracking angle. We
don’t use Sensors because it will become disorientated at dawn and
in cloudy conditions, so a backup tracking system is necessary in
the latter case.
FQA:
Q: The payment method you can accept?
A: Our payment method is different according to different countries
and regions.Normally, we accept payment by T/T.
Q: Are you a factory or trading company?
A: Yes,we are factory, supplying OEM/ODM service.
Q:How can I get some samples?
A: We can honored offer you samples according your inquiry.
Application
Agriculture Complementary
Single Axis Solar Tracker can be used in agriculture industry also,
it refers to the combination of agriculture and photovoltaic power
generation, normally photovoltaic panel can be installed on above
the fields, farmers can grow crops with low light requirements like
flowers and suffruticosa plants, the PV panels can provide a good
cover protecting for the plants under their shadow. The development
of photovoltaic power generation and Agriculture industry can
eventually form a good ecological co-development model.
