Slew Drive Smart Solar Tracking System Minimum Energy Consumption
Company Info:
Good Future Solar is a professional company in the market of solar
tracking system in China, we focus on research and development of
solar products like solar tracker system and tracker controller,
after years development, we have gain great business sense and rich
experience in the solar tracker market all over the world. Good
Future Solar could offer not only solar tracking system and
condenser, but also the professional service for solar plant design
and installation plan to our customers.
Parameters of Smart Solar Tracking System
| Technical Parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by PV strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
Company Values:
We believe that help our customer to get more success and value
creation is the company value, in this way we stick to giving top
priority to the interest of customers.
Product Info:
Good Future Smart Solar Tracking System uses high precision
tracking method “Astronomical algorithm + closed-loop control”, to
calculate the angle of the sun, under the control of slew driver
and controller system, the PV panels will rotate tracking with the
sunlight, this making the system more accurate and reliable, not
rainy days,snow days and other bad weather interference,using
international first-line brand tilt sensor, real-time closed-loop
feedback tracking angle, automatic tracking, without human
intervention.
Design Type of Solar Tracker
Normally the solar trackers could be classified to be single or
dual axis model according to the design and angle movement type.
Good future 1P/2P Smart Solar Tracking System is the single axis
trackers, it has one degree of freedom that acts as an axis of
rotation. Solar trackers can either have a horizontal or a vertical
axis. Good future Smart Solar Tracking System is horizontal type
and is used in regions where the daytime is short and sun gets very
high at noon. The vertical type is used in high latitudes where
summer days are very long but sun does not get very high.
Customized Functions
Rain and snow mode
Lora/CAN
Self-powered
Steel frame basis
Surroundings adapt custom made
According to Customer request custom made
Single Axis Solar Tracker Q&A:
Q: The payment method you can accept?
A: Our payment method is different according to different countries
and regions.Normally, we accept payment by T/T.
Q: Are you a factory or trading company?
A: Yes,we are factory, supplying OEM/ODM service.
Service:
We will give you a best service.
1) Reply inquiry within 24 hours.
2) Answer your detailed question.
3) Freight forwarder: faster, safer,and convenient.
4) Please kindly inform us which item you are interested in so that
the reasonable price could be provided soon.
