Independent Automatic Horizontal Single Axis Tracker
In PV plant, single axis solar trackers help minimize the angle of
incidence, which is the sunlight makes with a line perpendicular to
the panel surface. Minimizing the angle can increase the energy
that the PV plant produces.
The single axis solar tracker can move the angle of the tracker in
one direction as the day progresses. We will help you choose the
best direction for the single axis to pivot, but in general it will
pivot in a roughly East to West orientation. The solar panel will
begin the day facing the sunrise, and end it facing towards the
sunset.
Parameters of Independent Automatic Horizontal Single Axis Tracker
| Technical Parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by PV strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
About US
Good Future Solar is a high-tech company in the clean energy
industry, registered in China, address: Zhengzhou East New
District, Henan Province, China. Our company is committed to
provide the solar products of high reliability with competitive
price to our domestic and foreign customers. Strive to build our
brand in terms of leading technology, high quality and efficient
service.
Cost Effective Multi Row Solar Tracker Fast Installation
Automatic solar tracker, installation is simple, easy to expand
capacity, large capacity, low cost, strong wind resistance, high
economic performance, more suitable for low latitude area and high
requirements on flat ground.
The installation capacity and tracking range of the single axis
tracker is affected by the environment, and also limited by the
stroke of the mandrel jacking motor, good wind resistance,
relatively simple installation and high cost performance. If
installed on the slope, the advantages are more obvious.
1. Suitable for long row structure, a variety of foundation
applicable, save the amount of pile foundation;
2. Triple hardware and software protection + self-locking function,
reliability guarantee;
3. High cost gain: according to the layout optimization algorithm,
maximize the power generation;
4. Shorter operation and maintenance routes, saving operation and
maintenance costs;
5. Point to point monitoring, real-time monitoring to each tracking
device;
6. Differentiated navigation design, can realize fast installation.
Customized Functions
1. Smart control algorithm. Adopt time control + angle sensor to
form closed-loop control, no Angle accumulation error,
high-precision and reliable tracking;
2. Comprehensive protection mechanism. Wind protection, snow
protection, limit protection, over-current protection, over/under-
voltage protection, etc;
3. Fault self-diagnosis mechanism. System automatic detection,
automatic judgment, automatic alarm, automatic recovery after
troubleshooting, etc;
4. Modular design, easier for on-site troubleshooting and
maintenance;
5. Working temperature: -40℃ ~ 70℃;
6. Protection grade IP68, suitable for all kinds of outdoor
environments;
Product Application:
Single axis solar tracker is characterized by simple structure and
low cost. It is suitable for lower latitudes with high sun height
angle. Its power generation efficiency is 30% higher than fixed sun
panel tracking. The solar tracking system can be installed at
ground level or roof.
Payment Method:
As a professional solar tracker manufacturer and supplier, we can
accept L/C,D/A, D/P, T/T, Western Union and so on. But normally for
first order, we only accept T/T as only payment method. For all the
project we need the Advanced deposit according to the project
capacity, balance to be paid before shipment.
