Backtracking Solar Sun Tracker Utility Scale Easy Operation
Working principle:
A single-axis solar sun tracker follows the sun's azimuth
throughout the day. The tracker points the solar array to the east
in the morning and follows the sun across the sky to sunset in the
west, at which time it returns to its east-facing default position
to await the next sunrise. The single-axis tracker will not adjust
to compensate for the altitude, but the can be manually adjusted
through the year.
The tracking system is controlled by the tracking controller, with
simple structure, easy installation, flexible response, good
reliability and strong fault identification ability. Compared with
traditional fixed inclination installation, the generating capacity
can be increased by 15%-20% (depending on local conditions).
Technical Parameters of Solar Sun Tracker
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Ground Coverage Ratio | ≥ 25% |
| Foundation Options | All foundation types |
| Terrain Adaption | Up to 20% N-S slope |
| Structure Material | Hot dip galvanized steel |
| Power Consumption | 0.2-0.5kWh/day |
| Power Supply Mode | Powered by PV strings, back-up lithium battery |
| Operation Temperature | -40℃ - 70℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Advantage:
1. Suitable for all types modules on the markets.
2. High terrain tolerance, flat area, mountainous area.
3. Full automatic tracking, high tracking accuracy, less than 1℃.
4. Wireless monitoring system, and closed loop control, make the
system more reliable.
5. 100% bolted connections. No drilling, cutting, or welding
on-site.
6. High tracking accuracy, average tracking accuracy is ≤1°
7. The interval time of continuous tracking is adjustable;
8. Can execute to scheduled homing position in cloudy day or at
night;
9. Users can add external limit switch as needed;
10. Can move to scheduled position when there is wind ;
Pastoral Complementary
Single Axis Solar Tracker can be used in pastoral industry, it
refers to the combination of animal husbandry and photovoltaic
power generation, normally photovoltaic panel can be installed on
above the farm and prairie, cattle and sheep can be feeding under
the area below the photovoltaic pane, also the PV panels can
provide a good cover protecting for the animals under their shadow.
The development of photovoltaic power generation and animal
husbandry can eventually form a good ecological co-development
model.
Land Photovoltaic
Land photovoltaic power station refers to the construction of
photovoltaic power station under different terrain conditions such
as mountains, hills, desert, wasteland etc. The construction of
surface ups and downs, different orientations, the terrain can be
used irregular, scattered. Good Future Solar Technologies Co.,Ltd.
Will help to design the project according to terrain condition,
location and customer requirements.
