High Flexibility Solar Tracker System Low Energy Consumption
Working principle:
Single axis automatic tracking system are used to minimize the
angle of incidence between the incoming sunlight and a photovoltaic
panel. Reducing this angle increases the amount of energy produced
from a fixed amount of installed power generating capacity. As the
pricing, reliability and performance of single-axis trackers have
improved, the systems have been installed in an increasing
percentage of utility-scale projects.
Cost Effective Multi Row Solar Tracker Fast Installation
Automatic solar tracker, installation is simple, easy to expand
capacity, large capacity, low cost, strong wind resistance, high
economic performance, more suitable for low latitude area and high
requirements on flat ground.
The installation capacity and tracking range of the single axis
tracker is affected by the environment, and also limited by the
stroke of the mandrel jacking motor, good wind resistance,
relatively simple installation and high cost performance. If
installed on the slope, the advantages are more obvious.
1. Suitable for long row structure, a variety of foundation
applicable, save the amount of pile foundation;
2. Triple hardware and software protection + self-locking function,
reliability guarantee;
3. High cost gain: according to the layout optimization algorithm,
maximize the power generation;
4. Shorter operation and maintenance routes, saving operation and
maintenance costs;
5. Point to point monitoring, real-time monitoring to each tracking
device;
6. Differentiated navigation design, can realize fast installation.
Technical Parameters of Automatic Solar Tracker
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Ground Coverage Ratio | ≥ 25% |
| Foundation Options | All foundation types |
| Terrain Adaption | Up to 20% N-S slope |
| Module Supported | All commercially available modules |
| Operation Temperature | -40℃ - 70℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| String-Powered | Yes |
| Backtracking | Yes |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Service:
We will give you a best service.
1) Reply inquiry within 24 hours.
2) Answer your detailed question.
3) Freight forwarder: faster, safer,and convenient.
4) Please kindly inform us which item you are interested in so that
the reasonable price could be provided soon.
About us:
Good future solar has a professional management team, we have gains
rich experiences on the solar power generation, and the designing,
manufacturing, commissioning of the single axis tracking system.
Our company always values customer's needs as the highest priority,
ready to provides technical support to our customers at any time,
to solve their problems in the operation of PV power plant and
solar tracking system. With the mission of developing clean energy
and protecting the environment, we believe that through close
cooperation with domestic and foreign customers, we will continue
to innovate in technology and management, and create a bright
future of clean energy!
