    CE Single Axis Solar Tracker Galvanized Solar Tracker 20% N-S Slope

    Ask Lasest Price
    Brand Name : Good Future Solar
    Model Number : Independent solar tracker
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000MW per Month
    Delivery Time : 30 Working Days after design confirm
    • Product Details
    • Company Profile

    CE Single Axis Solar Tracker Galvanized Solar Tracker 20% N-S Slope

    Cost Effective Single Axis Solar Tracker System

    Working principle:
    Solar trackers are rising in popularity, solar panel tracking solutions are a more advanced technology for mounting photovoltaic panels. Stationary mounts, which hold panels in a fixed position, can have their productivity compromised when the sun passes to a less-than-optimal angle. Compensating for this, solar trackers automatically move to track the path of the sun across the sky, thereby maximizing output.
    Tracking controller according to the local longitude, latitude and time, the program automatically calculates the sun's trajectory at any time and the azimuth angle and altitude angle of the location. In the tracking stage, the system will automatically issue instructions according to the tracking range to control the operation of the electric actuator, and adjust the tracking angle every period of time so that the PV module is always aligned with the current sun position.

    Advantages:
    1. Optimal efficient installation
    Compare with the market, after project design and business accounting, the Good future Single Axis Tracker offers fewer foundations for each average MW.
    2. Simple link with tracker system Controller
    Good Future Solar offers different types of tracker controller: with/without Lithium battery or self-power controller. All these just need very easy link and no more operations after installation.
    3. High Reliability and Durability
    All the structures and accessories are using good material with high corrosion resistance quality and long life period, Good future Single Axis Tracker System protects itself in high wind and faults conditions.

    Features:
    1. High integration, internal integration: GPS global locator, high power motor drive chip, inclination sensor and tracking control system;

    2. Compact size, fully sealed waterproof and dust-proof, ultraviolet protection, suitable for outdoor installation;
    3. Easy installation, only need to access power supply, motor and limit switch 6 cables;
    No debugging. The device can be automatically tracked by placing it on the solar bracket without any debugging.

    Technical Parameters of Cost Effective Single Axis Solar Tracker System

    Technical parameters
    Tracking Range士 60°
    Driving SystemSlew drive, 28VDC motor
    Modules per TrackerMax.90 modules per tracker
    Foundation OptionsAll foundation types
    Terrain AdaptionUp to 20% N-S slope
    Structure MaterialHot dip galvanized steel
    Power Consumption0.2-0.5kWh/day
    Power Supply ModePowered by PV strings, back-up lithium battery
    Standard Design Wind Speed18m/s
    Module SupportedAll commercially available modules
    Operation Temperature-40℃ - 70℃
    Control AlgorithmAstronomical algorithms + Tilt sensor close loop
    Tracking Accuracy≤ 1°
    String poweredYes
    Night PositionYes

    CE Single Axis Solar Tracker Galvanized Solar Tracker 20% N-S Slope

    Business Scope
    1. Provide PV project related technical solutions to customers: from early planning to designing, from installation guidance to daily O&M, provide customers with complete technical support, technical consultation and training;
    2. Selection, designing, manufacturing and installation guidance of the single-axis tracking system for PV power plant;
    3. Complete supply chain of high-quality PV product components.
    4. Research and development of emerging industries such as charging and energy storage.
